DPR Virgo Compact Desktop Digital Finishing System
DPR Virgo Compact Desktop Digital Finishing System - VRG14PL (5" wide)
SKU:
The DPR Virgo is a powerful all-in-one desktop digital finishing system that unwinds, laminates, digitally die-cuts, removes waste, slits, and rewinds labels — delivering professional-grade finishing in a compact footprint.
Using advanced cutting-plotter technology and an integrated optical black-mark registration system, Virgo achieves exceptional accuracy and flexibility without the need for costly dies. It’s the perfect short-run finishing solution for businesses running digital color label printers and presses.
Product Resources
DPR VIRGO
Compact Desktop Digital Label Finishing System
-
-
Designed specifically for the compact VIRGO finisher, this optional table offers a stable surface for your connected laptop and convenient storage for printed or die-cut rolls. Equipped with smooth-rolling wheels, it provides easy mobility and workspace flexibility wherever you need it.
Table for Virgo (Optional)
-
The Virgo software integrates seamlessly with its built-in camera to form an optical black-mark registration system. Operators can import cutting files from Adobe Illustrator, CorelDRAW, or Inkscape, while the camera precisely detects the printed black marks to guide the plotter—ensuring accurate alignment and precise cutting on every label.
Cutting Manager Software
-
-
-
The optional Epson C6500A Printer Work Table transforms your setup into a complete, integrated label production system. Designed to streamline workflow from printing to finished labels, it enhances efficiency and organization for faster, more consistent output.
From Print to the Finished Label
Additional Information
-
Complete in-house label finishing: unwind, laminate, cut, strip, slit, and rewind
-
Digital workflow eliminates traditional dies and setup costs
-
Camera-assisted optical sensing for precise registration and faster throughput
-
Compact desktop design saves space and simplifies media loading
-
Pressing roller system ensures smooth, tear-free waste matrix removal
-
Adjustable clutch for consistent tension and perfectly wound rolls
-
Ultrasonic media tracking maintains steady web alignment
-
Multi-edge slitter blades extend blade life and reduce costs
-
Virgo software imports cut files from Adobe Illustrator, Corel DRAW, or Inkscape
-
Blank-label cutting mode—no black-mark needed
-
Remote assistance for diagnostics and firmware updates
| Specification | VRG14PL | VRG22PL |
|---|---|---|
| Input / Output Roll Diameter | 7.87″ (200 mm) | 7.87″ (200 mm) |
| Minimum Web Width | 4.34″ (110 mm) | 4.34″ (110 mm) |
| Maximum Web Width | 5.51″ (140 mm) | 8.86″ (225 mm) |
| Maximum Cutting Width | 4.80″ (122 mm) | 7.87″ (200 mm) |
| Minimum Slitting Width | 0.75″ (19 mm) | |
| Minimum Label Length | 0.39″ (10 mm) | |
| Maximum Label Length | 13.77″ (350 mm) with limitations | |
| Lamination Module | Yes | |
| Number of Slitting Blades | Up to 6 | Up to 8 |
| Maximum Media Thickness | 10 mil (0.25 mm) | |
| Maximum Cutting Speed | 24 in/s (600 mm/s) in all directions | |
| Roll Core Size | 3″ (76 mm) | |
| Agency Certifications | CE, FCC, RoHS | |
1-Year warranty on failures due to manufacturing defects but not to an incorrect use or negligence.
