DPR Taurus Laser Cutting & Laminating Machine
DPR Taurus Laser Cutting & Laminating Machine - TRS25PL (10in wide-30m/min)
SKU:
The DPR Taurus is a next-generation, fully digital label finishing system that fuses laser cutting, laminating, waste removal, slitting, and rewinding into one streamlined workflow. Eliminating the need for dies or manual cutters, Taurus enables on-demand, complex shape cutting at high speeds. With cutting capabilities of up to 30 m/min (98 ft/min) in any direction, this machine is engineered for flexibility, precision, and scalability.
Ideal for converters, label houses, and high-volume users, Taurus supports both pre-printed and blank media, and can laminate inline to boost label durability. It’s powered by a Galvo CO₂ laser, supports vector-based files, and offers dynamic three-axis control for variable laser power and cut depths.
Product Resources
DPR TAURUS
Industrial Laser Cutting & Laminating Machine
-
-
Up to 70m/min depending on laser power, cut pattern and material being used this finisher offers unwinding, laminating, digital cutting, waste removing, rewinding and length slitting in a single pass.
Fastest Finishing Speed
-
An innovative and smart cutting management software allows the operator to easily adjust the work speed and laser output for fabulous cutting , time optimization and less materials waste.
Cutting Manager Software
-
-
-
The UV Varnish module for the TAURUS laser finisher protects labels from damage, ensures high-quality results, and replaces noisy, wasteful foil lamination with an easy-to-use solution.
UV Varnish Mode
Additional Information
-
Die-free digital finishing — no expensive dies, drag knives, or tool changes
-
High-speed laser cutting — up to ≈ 30 m/min (98 ft/min) in any direction
-
Inline laminating — adds durability and environmental protection without interrupting the workflow
-
Matrix removal, slitting & rewinding — fully integrated finishing in one pass
-
Three-axis laser control (X, Y, Z) — supports variable depth and power on a single label
-
Supports vector-based file input for complex shapes and designs
-
Wide media compatibility — handles paper, plastic films (excluding some PET), and multiple substrate types (test media first)
-
Large roll capacity — input rolls up to Ø 500 mm, output up to Ø 400 mm
-
Eco & safety features — includes fume extraction compatibility, sealed CO₂ laser, cooling, and safety interlocks
| Models | TRS25PL Laser Label Finisher | TRS35PL / TRS35PL-PLUS Laser Label Finisher |
|---|---|---|
| Cutting Speed | 30 m/min | 30 m/min (TRS35PL) 70 m/min (TRS35PL-PLUS) |
| Input Roll Diameter | Up to 19.68" (500 mm) | Up to 19.68" (500 mm) |
| Output Roll Diameter | Up to 15.74" (400 mm) | Up to 15.74" (400 mm) |
| Cutting Area | 9.84" × 9.84" (250 × 250 mm) | 13" × 13" (330 × 330 mm) |
| Web Width | 1.96" – 9.84" (50 – 250 mm) | 1.96" – 13.78" (50 – 350 mm) |
| Laser Spot Size | Up to 250 μm | Up to 350 μm |
| Laser Source Power | 150 W – 10.25 μm | 350 W – 10.25 μm |
| Power Requirement | 220 VAC, 18 A, 4000 W | 220 VAC, 34 A, 7500 W |
| Laser Type | Single Head CO₂ | |
| Type of Cut | Kiss-cut, full cut, perforation, engraving | |
| Media Type Allowed | Paper, plastic films (except PET) | |
1-Year warranty on failures due to manufacturing defects but not to an incorrect use or negligence.
