Duplo
Duplo DPC-2024 Digital Die Cutter
Duplo DPC-2024 Digital Die Cutter - Default Title
SKU:
The DocuCutter DPC-2024 Digital Die Cutter combines its capacity to support oversize B2 sheets with 24” vinyl cutting technology. The DPC-2024 handles substrates such as paper, laminates, and adhesive stocks up to 350 gsm to produce applications from pocket folders to custom boxes. Each sheet is guided back and forth on the cutting pad by three multi-pressure pinch rollers. It comes included with a cutting knife and scoring pen to process printed output in addition to a vinyl cutting knife for finishing decals on demand.
Features
- Easy job file preparation and set up
- Quick changeover from paper to vinyl cutting
- Automated feeding with adjustable trays
- Dual tooling head and Flexi 19 software
Product Resources
See It In Action
-
NO PHYSICAL DIES REQUIREDFully digital cutting, creasing, and perforating without tooling costs
-
Supports larger format sheets for packaging and specialty applications.
UP TO 21" X 30" SHEET SIZE -
Cut, score, and perforate in a single automated workflow.
MULTI-TOOL CUTTING SYSTEM -
COMPACT FOOTPRINTDesigned to integrate smoothly into digital finishing workflows
-
Ideal for prototypes, custom cartons, and specialty printed pieces
SHORT-RUN & PROTOTYPE READY
-
-
Digital Die Cutting Without Tooling Costs
The DPC-2024 eliminates the need for traditional metal dies, allowing print providers to produce custom shapes and packaging instantly. This dramatically reduces setup time and makes short-run, personalized, and prototype jobs more profitable.
-
Expand Into High-Value Packaging Applications
Designed to handle larger sheet sizes and thicker materials, the DPC-2024 opens new opportunities in packaging, specialty print, and custom die-cut products. Its precise registration and multi-tool system deliver clean, professional results every time.
-
Features
- Automated Sheet Feeding
Reliable feeding system designed for steady, unattended production. - Supports Heavy Stocks
Handles thicker substrates for packaging and specialty applications - Fast Job Changeovers
Quickly switch between designs with minimal downtime. - User-Friendly Control Software
Manage layouts and adjustments through intuitive PC-based controls. - Short-Run Packaging Ready
Ideal for prototypes, cartons, and custom packaging pieces. - Flexible Layout Capability
Easily produce unique shapes, windows, and intricate designs.
Additional Information
| AUTO FEED | |
|---|---|
| Feeder Capacity | Up to 50 mm |
| Feeding System | Automatic suction feeder |
| Sheet Size | Min. 8.5" x 11" / Max. 20.87" x 29.53" |
| VINYL ROLL FEED | |
| Max. Roll Width | 24" |
| Max. Cutting Area (W x L) | 21 inches x 19.68 feet |
| Min. Cutting Length | 2" |
| CUTTING CONTROL | |
| Cutting System | Plotter Cutter |
| Max. Cutting Speed | 1,530 mm/second (60 ips at 45° direction) |
| Cutting Thickness | 350 gsm |
| Cutting Tolerance | ±0.1 mm |
| Cutting Force | 5 – 600 g |
| SOFTWARE AND CONNECTION | |
| Software (Platform) | DPC-2024 Windows driver (Adobe Illustrator Plug-in) and Flexi 19 |
| File Format | |
| Network | USB 2.0 (Full Speed), Serial (RS-232C), and Ethernet |
| GENERAL | |
| Standard Features | 4 tools (green cap blade, scoring pen, red cap blade, cut-off blade), Flexi 19 software and DPC-2024 Windows driver (PC sold separately), 2-roller attachment, feed and receiving trays, waste basket, stands |
| Safety | ETL / cETL certified |
| Power Requirements | Cutter: 100–240 VAC, 3.0A, 50/60Hz Feeder: 100–240 VAC, 2.1A, 50/60Hz |
| Dimensions (L x W x H) | 65" x 43" x 49" (1,651 mm x 1,092 mm x 1,245 mm) |
| Net Weight | Cutter: 56 lb / 25 kg Feeder: 49 lb / 22 kg Stand/Catch Tray: 88 lb / 40 kg |
