• Ultra Quiet - Only 70 decibels
-
• Oil-Free Pump – Cleaner air for better tool operation
-
• Less Maintenance and Costs
-
• Two - 1/4″ Industrial female quick connectors
-
• Portable Design - Wheel Kit & Handle for Easy Transport
-
• Thermal Overload Protector
Easy to Set Up
Install the silencer
Install the joint
Install the hose joint
Install the dust gun
Additional Information
| Rated/Running HP | 2.2 HP |
| Tank Capacity | 50 Liter Steel Tank |
| Air Flow | 140 L/min (≈ 5.0 CFM @ 90 PSI / 6.0 CFM @ 40 PSI) |
| Max Pressure | 8 bar (≈ 115 PSI) |
| Voltage/Frequency | 110V / 60Hz |
| Low Amp Draw | ~14 Amps |
| Electrical Requirement | Dedicated 15A outlet recommended (14-gauge cord, 25 ft max length) |
| Portable Power Requirement | Min. 5500W Generator |
| Time to Fill Tank (0–115 PSI) | ~120 Seconds |
| Recovery Time (95–115 PSI) | ~25 Seconds |
| Duty Cycle | 70/30 (Max continuous running 30–60 min depending on PSI & CFM) |
| Operation Type | Oil-Free – Ideal for cold starts & uneven surfaces |
| Noise Level | 70 dB (Ultra Quiet) |
| Motor Speed | 2800 RPM |
| Protection | Thermal Protection Switch – Prevents overheating |
| Motor Type | Copper Coil Motor – Long service life |
| Design | Portable – Wheel kit & handle for easy transport |
| Dimensions | 33" (L) × 15" (W) × 28" (H) |
| Weight | 70 lbs (32 kg) |
| Warranty | 1 Year Limited |
| Certification | UL Certified |
-
Dust Gun
-
Hose
-
Two Air Filters
-
Wheel Kit
